Works with the machines you already run

Works with your machines.

The gateway speaks the protocols your PLCs already speak. Point the commissioning wizard at a machine, pick your protocol, and it finds the tags live. No rip-and-replace, no new controllers.

Connected machines

18 protocols, compatible with hundreds of machine models.

CNC, injection molding, extrusion, welding, and legacy controls. Read-only, no VPN, no static IP.

FANUC Siemens Mazak Haas DMG MORI Citizen Arburg Toshiba Mitsubishi
Okuma Makino Doosan Hurco ENGEL Allen-Bradley Omron Lincoln Electric Hypertherm
MTConnect OPC UA Modbus MQTT + 14 more →

Plus any machine running a FANUC, Siemens, or Mitsubishi control, whatever badge is on the sheet metal.

All product names and marks belong to their owners. Compatibility statement, not endorsement.

$200/machine/mo · pilots from $4,500 · hardware included

See full pricing →

No controller? No problem.

Older presses, saws, manual mills: wired in too.

A machine with no network drop and no tags is the Direct-wired row in the table above: 4-20mA analog inputs (a standard clamp-on current transducer wires straight in), isolated digital inputs for dry contacts and stack lights, and a relay output. Our tech does that wiring during install, the same as we do your PLCs. One gateway covers the deep protocols in the table above and the machines that don't have any, no second vendor, no second box.

PLCs & controllers

The controllers running your lines.

OPC-UA

Ethernet

The modern universal standard. Most PLCs built since ~2010 expose an OPC-UA server, across every major vendor. The easy default when a machine supports it.

Siemens S7

Ethernet

S7-300, S7-400, S7-1200 and S7-1500 controllers.

Allen-Bradley (EtherNet/IP)

Ethernet

ControlLogix, CompactLogix and other EtherNet/IP Rockwell controllers, by tag name.

Allen-Bradley (PLC-5 / SLC 500)

Ethernet

Older Rockwell PLC-5 and SLC 500 families over Ethernet.

Allen-Bradley Micro800

Ethernet

Micro800-series micro-PLCs: IP address and go.

Allen-Bradley DH+

Networked

SLC / PLC-5 controllers reached across a legacy DH+ network through a bridge.

Omron

Ethernet

Omron NJ, NX and CJ controllers by symbolic tag.

Mitsubishi (Ethernet)

Ethernet

Mitsubishi Q, L, QnA and iQ-R series over Ethernet.

Mitsubishi (Serial)

Serial

The same Mitsubishi families for machines with no Ethernet port.

LS Electric XGT (Ethernet)

Ethernet

LS Electric XGT-series PLCs over Ethernet.

LS Electric XGT (Serial)

Serial

XGT-series over a serial connection.

CNC, sensors & meters

Machines, meters, and wires.

FANUC CNC (FOCAS)

Ethernet

FANUC CNC controllers: spindle speed, feed rate, alarms and program status.

MTConnect

Ethernet

The machine-tool standard. Any CNC with an MTConnect agent: availability, execution state, spindle load, alarms, program.

Modbus TCP

Ethernet

Generic Modbus devices: VFDs, power meters, PLCs, gateways.

Modbus RTU

Serial

Legacy serial Modbus devices over RS-485 / RS-232, usually via a USB adapter.

Direct-wired sensors

Direct-wired

Isolated digital inputs for dry contacts, stack lights and cycle switches, plus a relay output to drive a light or buzzer straight off a data event. No PLC required.

Analog sensors

Direct-wired

4-20mA and 0-10V analog sensors read directly by the gateway. A clamp-on current transducer around a power lead is the common case, and the same inputs take vibration or temperature transmitters on spindles, pumps, and motors: the AI watches the trends and alerts your team. No PLC, no tags, no controller at all.

Anything else

For the stragglers.

Web / XML status feeds

Network

Machines or gateways that publish status to a web page or XML feed.

Custom / other

Configurable

An escape hatch: anything else with a documented protocol. Bring it to the pilot call and we'll wire it up.

Not sure which one?

Find your machine.

Your machine What it uses
Siemens S7-300 / S7-400 / S7-1200 / S7-1500 Siemens S7
Rockwell ControlLogix / CompactLogix (Logix, EtherNet/IP) Allen-Bradley (EtherNet/IP)
Rockwell PLC-5 / SLC 500 Allen-Bradley (PLC-5 / SLC 500)
Rockwell Micro800 Allen-Bradley Micro800
Rockwell PLC-5 / SLC 500 over DH+ (legacy network, bridged) Allen-Bradley DH+
Omron NJ / NX / CJ Omron
Mitsubishi Q / L / QnA / iQ-R (Ethernet) Mitsubishi (Ethernet)
Mitsubishi Q / L / QnA / iQ-R, no Ethernet port Mitsubishi (Serial)
LS Electric XGT (Ethernet or Serial) LS Electric XGT
Any modern PLC with OPC-UA OPC-UA
FANUC CNC FANUC (FOCAS)
Haas, Mazak, Okuma, DMG MORI, Hurco, Makino, Doosan, or any CNC with MTConnect MTConnect
VFDs, power meters, or generic Modbus devices Modbus TCP
Legacy serial Modbus devices Modbus RTU
A machine or gateway that publishes a web page or XML status feed Web / XML status feed
Discrete sensors, stack lights, dry contacts, or cycle switches, no PLC Direct-wired digital I/O
4-20mA / 0-10V analog sensors, with or without a PLC Analog input (ADC)
Something else, with a documented protocol Custom / other

Something unusual on the floor? The commissioning wizard tests any tag live before you commit. Bring your list to the pilot call and we'll tell you exactly what plugs in.

Bring your machine list. We'll tell you exactly what plugs in.

30-day pilot, hardware included, from $4,500, fully credited when you expand.
